High Pressure DIN EN853 1SN-K Hydraulic Hose

DIN EN853 1SN-K Hydraulic Hose is One steel wire braided hose standard exceeds EN853 1SN standard. it can withstanding higher pressures than standard EN 853 1SN hose. High pressure 1snk hoses are used for most hydraulic systems of mobile machines and equipment with medium pressure., which operate under normal temperature conditions and in non-aggressive environments.  It is composed of three parts: tube, reinforcement and cover. It is resistant to abrasion and corrosion due to the tube. And it can work well in high pressure environment thanks to its high tensile steel wire reinforcement. Besides, it is resistant to weather, ozone, aging and sunlight because of the cover with the cloth impression.

Applicable Specs:

■ ISO 18752 1BC/1CC ■ DIN EN 857 1SC+-Exceeds EN857 1SC ■ DIN EN 853 1SNK-Exceeds EN853 1SN

■ ISO 1436:2009 ■ TS 6387 EN857 1SC ■ ISO 1307 ■ ISO 6805 ■ EN 13463-1 ■ GOST 6268 1SN

CONSTRUÇÃO:
Tubo: Synthetic rubber, extruded whole without joints, of uniform thickness

Reforço: 1 layer of steel wire braid

Cobrir: Borracha sintética antiabrasiva, resistente a óleos, combustíveis e condições atmosféricas

TEMPERATURA:

• -40 °C to +100 °C (intermittent 120 °C)
• -40 °C to +70 °C for water based fluids
• 0 °C to +70 °C hot air

Prolonged operation at extreme temperatures will reduce hoses life

APLICATIVO:

Mineral and biological oils, glicol-water based, water, lubricants

Pressão no trabalho:

110–290 Bar / 1595–4205 PSI

Impulse times:

≥ 300,000 Times

The specification of EB 853 1SN-K steel wire reinforced hydraulic hose
