90° JIS METRIC FEMALE 60° CONE SEAT SEAL (28691)
90° JIS METRIC FEMALE 60° CONE SEAT SEAL (28691)
Material: carbon steel, stainless steel, brass;
Surface Treat: galvanize Yellow Zinc, Black Zinc, Cr6 free Zinc, and Nickel;
Application: widely used in the hydraulic and fluid conveying system of machinery, oilfield, mine, building, transportation, food, and other industries.
Products Specification:
|
E |
HOSE ORE |
DIMENSIONS |
|||||
|
PART NO. |
THREAD E |
DN |
DASH |
C |
S1 |
S2 |
H |
|
28691-14-04 |
M14X1.5 |
6 |
04 |
10.5 |
19 |
19 |
38 |
|
28691-14-06 |
M14X1.5 |
10 |
06 |
10.5 |
19 |
19 |
43.3 |
|
28691-16-05 |
M16X1.5 |
8 |
05 |
9.3 |
22 |
22 |
44 |
|
28691-18-06 |
M18X1.5 |
10 |
06 |
11.5 |
24 |
24 |
46.3 |
|
28691-22-08 |
M22X1.5 |
12 |
08 |
14 |
27 |
27 |
52.5 |
|
28691-24-10 |
M24X1.5 |
16 |
10 |
15.1 |
32 |
32 |
59 |
|
28691-30-12 |
M30X1.5 |
20 |
12 |
18.3 |
36 |
36 |
68.5 |
|
28691-33-16 |
M33X1.5 |
25 |
16 |
21.3 |
41 |
41 |
76 |
|
28691-36-20 |
M36X1.5 |
32 |
20 |
20 |
46 |
46 |
88 |
Note:1.For use with braided hoses. 2. If used with spiral hoses, the hose fitting series number is 28692-XX-XX
