Hydraulic Hose Crimping Machine
Hydraulic hose crimping machines are used to crimp hoses and fittings to create a tight seal. The machine works by using a hydraulic pump to pressurize a die set, which is then used to crimp the hose and fitting together. The machine is typically used in industrial and automotive applications, and is capable of crimping hoses and fittings of various sizes and materials.
Hydraulic Hose Crimping Machine features:
1. The hydraulic hose crimping machine has a PLC control system, which can realize automatic and manual operation.
2. The hydraulic hose crimping machine is equipped with a touch screen that displays the machine’s working parameters and operational status.
3. The hydraulic hose crimping machine is equipped with a pressure sensor, which can accurately detect the machine’s pressure and ensure crimping accuracy.
Crimping range:φ6~φ51 mm
Scale accuracy:0.02 mm
Motor Power:3KW +0.75KW
Crimping pressure:407 T
Pump Displacement:10L/min
Rotate speed: 1420r/min
Rated pressure:20MPa
Weight:270 Kg
Size:850×430×1030(mm)
Dies 10 sets :Φ16、Φ19、Φ23、Φ26、Φ30、Φ34、Φ38、Φ45、Φ52、Φ63
Crimping range:Φ6—Φ51mm
Max crimping pressure:400T
Scale accuracy:0.02mm
Rated pressure:31.5MPa
Pump displacement:5ml/rad (380V) 2.5ml/rad (220V)
Size:670×490×780mm
Weight:260kg
Dies 10 sets:Φ16、Φ19、Φ23、Φ26、Φ30、Φ34、Φ38、Φ45、Φ52、Φ63
Crimping range:Φ6—Φ51mm
Max crimping pressure:407T
Scale accuracy:0.02mm
Rated pressure:20MPa
Pump displacement:10ml/rad
Rotate speed:1440 r/min
Weight:270kg
Motor Power:4kw
Size:850×450×1300mm
Dies 10 sets:Φ16、Φ19、Φ23、Φ26、Φ30、Φ34、Φ38、Φ45、Φ52、Φ63
Crimping range:Φ6—Φ51mm
Max crimping pressure:640T
Scale accuracy:0.02mm
Rated pressure:31.5MPa
Pump displacement:10ml/rad
Rotate speed:1440 r/min
Weight:270kg
Motor power:4kw
Size:850×450×1300mm
Dies 10 sets:Φ16、Φ19、Φ23、Φ26、Φ30、Φ34、Φ38、Φ45、Φ52、Φ63
Crimping range:φ6~φ51 mm
Max measure: 120 mm
Closed expansion range: ±25 mm
Scale accuracy:0.02 mm
Crimping pressure:540 T
Rated pressure: 31.5MPa
Pump displacement:14 L/min
Weight:350Kg
Motor power:4KW (oil pump motor)
Size:800×620×1300mm
Dies 10 sets:Φ16、Φ19、Φ23、Φ26、Φ30、Φ34、Φ38、Φ45、Φ52、Φ63
Crimping size:φ6~φ102 mm
Scale accuracy:0.02 mm
Motor power:5.5KW
Crimping pressure:1070 T
Rotate speed: 1440r/min
Pump displacement:36L/min
Weight:1500 Kg
Oil tank capacity:200 L
Dies 18 sets:Φ13、 Φ 17、 Φ21、Φ24 、Φ28 、Φ31 、Φ34、 Φ38、Φ42 、Φ45、Φ50、Φ56、Φ60、Φ65、Φ78、Φ90、Φ104、Φ118
Model: JKS-200
Oil cylinder pushing force:47T
Pump displacement:30ml
Hydraulic oil :Summer YB-N46
Winter: YB-N32
Crimping range:φ6-φ32
Weight:100kg
Size:600×500×370mm
Dies eight sets
